Place of Origin:
Guangzhou China
Brand Name:
Kablee
Certification:
RoHS/REACH/ELV/IATF16949:2016
Model Number:
T01
Contact Us
Video
Video
Automotive Wire harness cloth tapes are adhesive tapes specifically designed for the purpose of bundling and securing wire harnesses in various applications. They are commonly used in industries such as automotive, aerospace, electronics, and electrical engineering. When it comes to cloth tapes, various specifications can vary depending on the specific product and manufacturer. However, here are some common specifications and characteristics associated with cloth tapes:
1. Material: Cloth tapes are typically made from PET fabric. The choice of material affects the tape's overall strength, flexibility, and resistance to abrasion.
2. Adhesive: Cloth tapes have an adhesive backing that allows them to adhere to surfaces. The adhesive can be rubber-based, acrylic-based, or a combination of both. The adhesive properties determine the tape's bonding strength and its ability to stick to different surfaces.
3. Width and Length: Cloth tapes are available in different widths, typically ranging from ½ inch to several inches. The length can vary as well, ranging from a few yards to several hundred yards per roll.
4. Thickness: The thickness of cloth tapes can vary, typically ranging from 0.18-0.2mm. Thicker tapes offer increased durability and protection.
5. Tensile Strength: Tensile strength refers to the maximum amount of force or stress the tape can withstand before breaking. It is an important specification to consider, especially in applications where the tape will be subjected to tension or pulling forces.
6. Temperature Resistance: Cloth tapes may have different temperature resistance capabilities. Some tapes are designed to withstand high temperatures, while others have a lower tolerance. It is important to choose a tape that can withstand the temperatures expected in the application environment.
| Parameter | Value |
|---|---|
| Adhesive | Acrylates Copolymer |
| Material | Polyester PET |
| Chemical Resistant | Yes |
| 180°Peel-off Strength | ≥1.5N/cm |
| Flame retardation | Class B Self-extinguishing |
| Thickness | 0.2mm |
| Moisture Resistant | Yes |
| Tensile Strength | ≥20N/cm |
| Abrasion Resistant | Yes |
| Flame Retardant | Yes |
At Automotive Wire Harness Tape, we understand that our customers rely on our products to perform reliably, safely, and efficiently. That's why we offer comprehensive technical support and service for all our products. Our team of engineers and technicians is ready to provide you with on-site assistance for any questions or issues you may have.
