Place of Origin:
Guangzhou China
Brand Name:
Kablee
Certification:
RoHS/REACH/ELV/IATF16949:2016
Model Number:
L11
Contact Us
Video
Video
The main purpose of wire harness tape is to protect the wires and cables from abrasion, moisture, and other external factors that may damage the insulation or conductivity. It provides a layer of insulation and helps to secure the wires in place, preventing them from moving or rubbing against each other.
Some advantages of wire harness tape include its flexibility, easy tearability, and repositionability. It can be torn by hand without the need for scissors or knives, making it convenient to work with. The tape can also be easily repositioned or removed if adjustments are needed during the wiring process.
Wire harness tape is commonly used in automotive, aerospace, and electrical industries. It is often used in wire harnesses, where multiple wires are bundled together, as well as in electrical repairs and installations. The tape is also used to provide additional insulation in high-temperature applications.
Kablee Solution Characteristics:
with performance of noise damp and abrasion resistance
with flexibility and high abrasion
Lower VOC and NVOC
Special adhesive for high temp and thermal shock
Pass RoHS/REACH/ELV standard
Meet OEM growing odor test requirements
Automotive Laminated Tape Technical Diameter:
| Item | Result |
|
Width
|
19mm±0.20
25mm±0.20
|
|
Thickness
|
0.4mm±0.02
|
|
180°peel-off strength
(under normal condition
|
≥1.5N/cm |
|
180°peel-off strength
(after being heated)
|
≥2N/cm |
|
Tensile strength
(under normal condition)
|
34N/CM |
|
Stretch performance
(under normal condition
|
≥20%
|
|
Tensile strength
(after being heated)
|
35N/CM |
|
Cold resistance
|
no harmful break or crack
|
| Abrasion resistance (Scrape) | Class D 1000～4999 |
| Flame retardation | Class B self-extinguishing |
Our main customers:
