Place of Origin:
Guangzhou China
Brand Name:
Kablee
Certification:
RoHS/REACH/ELV/IATF16949:2016
Model Number:
T03
Contact Us
Video
Video
Automotive harness tape is a type of specialized tape designed specifically for use in automotive wire harnesses. It provides protection, insulation, and secure bundling of wires in the harsh conditions of a vehicle's engine compartment. Automotive harness tape typically has the following characteristics:
1. Heat resistance: It can withstand high temperatures encountered in the engine bay to prevent melting or adhesive failure. The tape should be able to handle temperatures up to at least 105°C (221°F) or higher.
2. Abrasion resistance: It offers protection against abrasion and friction caused by the movement of wires, vibration, and contact with sharp edges or components.
3. Electrical insulation: It provides electrical insulation to prevent short circuits and ensure proper functioning of the wires.
4. Noise reduction: Some automotive harness tapes are designed to dampen or reduce noise and vibrations caused by wire movement or contact with other components.
5. Self-adhesive: Automotive harness tapes typically have a self-adhesive backing that eliminates the need for additional adhesives. This adhesive should have good bonding strength and long-lasting adhesion.
| Product Name | Wire Harness Wrapping Tape |
|---|---|
| Application | Wire Harness Wrapping |
| Material | Polyester Fabric Material |
| Color | Black Color |
| Total Thickness | 0.16mm |
| Adhesion to Steel | 2.5N/CM |
| Elongation | 60% |
| Flammability | Class B self-extinguishing |
| Temperature Range | -20℃~105℃ |
| Printability | Yes |
Wire harness wrapping tape is commonly used in automotive and electrical applications to protect and secure wire harnesses. It provides insulation, abrasion resistance, and helps organize and bundle the wires together. Here's a step-by-step guide on how to apply wire harness wrapping tape:
1. Prepare the wire harness: Ensure that the wires are properly organized and positioned before applying the tape. Remove any dirt, oil, or debris from the harness to ensure good adhesion.
2. Choose the right tape: Select a wire harness wrapping tape that suits your specific needs. There are different types of tapes available, such as cloth tape, vinyl tape, or fleece tape. Consider factors like temperature resistance, flexibility, and electrical insulation properties.
3. Apply tension: Apply gentle tension to the tape as you wrap it around the wire harness. This tension helps create a secure and snug fit. Be careful not to pull too tightly, as it may damage the wires or restrict movement.
4. Overlap and continue wrapping: Continue wrapping the tape around the wire harness, maintaining the overlap and tension. Ensure that each wrap slightly covers the previous one to provide a complete coverage.
5. Smooth out wrinkles and air bubbles: As you wrap, smooth out any wrinkles or air bubbles that may form. This helps ensure a neat and uniform appearance while maximizing the tape's protective properties.
Wire Harness Wrapping Tape provides the following technical support and services:
