Place of Origin:
Guangzhou China
Brand Name:
Kablee
Certification:
RoHS/REACH/ELV/IATF16949:2016
Model Number:
T03
Contact Us
Video
Video
Wire Harness Wrapping Tape is an adhesive tape specially designed for automotive wire harness wrapping. The tape is made of high quality polyester fabric, providing excellent dielectric strength of ≥20KV/mm, excellent adhesion to steel of 2.5N/CM, and superior abrasion, temperature and UV resistance. The size of the tape is 19mm*25m, allowing for multiple wrapping applications. The tape can be used for a variety of wire harness wrapping applications, including automotive, electrical, and electronic industries. It has excellent adhesion to most surfaces, providing a secure and reliable seal for wire harnesses. The tape is easy to use and install, making it ideal for automotive wire harness wrapping.
| Product Name | Wire Harness Wrapping Tape |
|---|---|
| Application | Wire Harness Wrapping |
| Material | Polyester Fabric |
| Color | Orange |
| Total Thickness | 0.16mm |
| Adhesion to Steel | 2.5N/CM |
| Elongation | 60% |
| Flammability | Class B self-extinguishing |
| Temperature Range | -20℃~105℃ |
| Printability | Yes |
Wire harness wrapping tape is commonly used in automotive and electrical applications to protect and secure wire harnesses. It provides insulation, abrasion resistance, and helps organize and bundle the wires together. Here's a step-by-step guide on how to apply wire harness wrapping tape:
1. Prepare the wire harness: Ensure that the wires are properly organized and positioned before applying the tape. Remove any dirt, oil, or debris from the harness to ensure good adhesion.
2. Choose the right tape: Select a wire harness wrapping tape that suits your specific needs. There are different types of tapes available, such as cloth tape, vinyl tape, or fleece tape. Consider factors like temperature resistance, flexibility, and electrical insulation properties.
3. Start at one end: Begin the application at one end of the wire harness. Leave a small portion of the tape's adhesive backing exposed to allow for easy removal when necessary.
4. Position the tape: Hold the tape at a slight angle to the wire harness, making sure the adhesive side is facing the harness. Position the tape so that it overlaps the previous wrap by approximately half of its width.
5. Apply tension: Apply gentle tension to the tape as you wrap it around the wire harness. This tension helps create a secure and snug fit. Be careful not to pull too tightly, as it may damage the wires or restrict movement.
6. Overlap and continue wrapping: Continue wrapping the tape around the wire harness, maintaining the overlap and tension. Ensure that each wrap slightly covers the previous one to provide a complete coverage.
7. Smooth out wrinkles and air bubbles: As you wrap, smooth out any wrinkles or air bubbles that may form. This helps ensure a neat and uniform appearance while maximizing the tape's protective properties.
Wire Harness Wrapping Tape provides the following technical support and services:
