Polyester Fabric Wire Harness Wrapping Tape For Automotive Harness Long-lasting Protection

Polyester Fabric Wire Harness Wrapping Tape For Automotive Harness Long-lasting Protection

Automotive Harness Wrapping Tape

Long-lasting Protection Wrapping Tape

Polyester Fabric Wrapping Tape

Place of Origin:

Guangzhou China

Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Dielectric Strength:
Temperature Range:
Tensile Strength:
Payment & Shipping Terms
Minimum Order Quantity
1 carton
Packaging Details
Carton Box
Delivery Time
within 5-7days
Payment Terms
T/T, Paypal
Supply Ability
1000 cartons per day
Product Description

Polyester Fabric Wire Harness Wrapping Tape for Automotive Harness Long-lasting Protection

Product Description:

Wire Harness Wrapping Tape is an adhesive tape specially designed for automotive wire harness wrapping. The tape is made of high quality polyester fabric, providing excellent dielectric strength of ≥20KV/mm, excellent adhesion to steel of 2.5N/CM, and superior abrasion, temperature and UV resistance. The size of the tape is 19mm*25m, allowing for multiple wrapping applications. The tape can be used for a variety of wire harness wrapping applications, including automotive, electrical, and electronic industries. It has excellent adhesion to most surfaces, providing a secure and reliable seal for wire harnesses. The tape is easy to use and install, making it ideal for automotive wire harness wrapping.



  • Product Name: Wire Harness Wrapping Tape
  • Adhesive: Acrylic
  • Total Thickness: 0.16mm
  • Size: 19mm*25m
  • Temperature Range: -40℃~105℃
  • Material: Polyester Fabric

Technical Parameters:

Product Name Wire Harness Wrapping Tape
Application Wire Harness Wrapping
Material Polyester Fabric
Color Orange
Total Thickness 0.16mm
Adhesion to Steel 2.5N/CM
Elongation 60%
Flammability Class B
Temperature Range -20℃~105℃
Printability Yes


Wire harness wrapping tape is commonly used in automotive and electrical applications to protect and secure wire harnesses. It provides insulation, abrasion resistance, and helps organize and bundle the wires together. Here's a step-by-step guide on how to apply wire harness wrapping tape:

1. Prepare the wire harness: Ensure that the wires are properly organized and positioned before applying the tape. Remove any dirt, oil, or debris from the harness to ensure good adhesion.
2. Choose the right tape: Select a wire harness wrapping tape that suits your specific needs. There are different types of tapes available, such as cloth tape, vinyl tape, or fleece tape. Consider factors like temperature resistance, flexibility, and electrical insulation properties.

3. Start at one end: Begin the application at one end of the wire harness. Leave a small portion of the tape's adhesive backing exposed to allow for easy removal when necessary.
4. Position the tape: Hold the tape at a slight angle to the wire harness, making sure the adhesive side is facing the harness. Position the tape so that it overlaps the previous wrap by approximately half of its width.
5. Apply tension: Apply gentle tension to the tape as you wrap it around the wire harness. This tension helps create a secure and snug fit. Be careful not to pull too tightly, as it may damage the wires or restrict movement.
6. Overlap and continue wrapping: Continue wrapping the tape around the wire harness, maintaining the overlap and tension. Ensure that each wrap slightly covers the previous one to provide a complete coverage.

7. Smooth out wrinkles and air bubbles: As you wrap, smooth out any wrinkles or air bubbles that may form. This helps ensure a neat and uniform appearance while maximizing the tape's protective properties.
8. Secure the end: When you reach the end of the wire harness, cut the tape, leaving a small portion exposed to facilitate future removal. Press the end firmly to secure it in place.
9. Final inspection: Once the tape is applied, inspect the wire harness to ensure complete coverage and proper adhesion. Check for any exposed wires or areas that may require additional tape.



Support and Services:

Wire Harness Wrapping Tape Technical Support and Services

Wire Harness Wrapping Tape provides the following technical support and services:

  • Help diagnose and troubleshoot Wire Harness Wrapping Tape related problems
  • Provide product information and installation instructions
  • Provide guidance on product selection and application
  • Provide product warranty information
  • Provide product maintenance and repair services
  • Provide product replacement services


Q:What is the brand name of the Wire Harness Wrapping Tape?
A:The brand name of the Wire Harness Wrapping Tape is Kablee.
Q:What is the model number of the Wire Harness Wrapping Tape?
A:The model number of the Wire Harness Wrapping Tape is T03(O).
Q:Where is the Wire Harness Wrapping Tape made?
A:The Wire Harness Wrapping Tape is made in Guangzhou, China.
Q:What certifications does the Wire Harness Wrapping Tape have?
A:The Wire Harness Wrapping Tape has RoHS/REACH/ELV/IATF16949:2016 certifications.
Q:What is the minimum order quantity of the Wire Harness Wrapping Tape?
A:The minimum order quantity of the Wire Harness Wrapping Tape is 1 carton.
