Flame Retardant Insulation PVC Tape 25m Length For Electrical Insulation

Flame Retardant Insulation PVC Tape 25m Length For Electrical Insulation

Flame Retardant Insulation PVC Tape

Insulation PVC Tape Electrical

25m electrical insulation tape

Place of Origin:

Guangzhou China

Brand Name:

Kablee

Certification:

RoHS/REACH/ELV/IATF16949:2016

Model Number:

P06

Contact Us

Request A Quote
Product Details
Material:
PVC
Length:
25m
Tensile Strength:
≥19.6N/19mm
Thickness:
0.1mm
Elongation:
≥100%
Insulation Resistance:
≥20MΩ
Application:
Electrical Insulation
Color:
Black/White/Orange/Yellow
Payment & Shipping Terms
Minimum Order Quantity
1 carton
Price
0.01-0.02
Packaging Details
Carton Box
Delivery Time
within 5-7days
Payment Terms
T/T, Paypal
Supply Ability
500 cartons per day
Product Description

Flame Retardant PVC Insulation Tape -10℃~105℃ Class B Self-extinguishing

Product Description:

Insulation PVC Tape: PVC Wire Harness Tape with Electrical Insulation, Tensile Strength, Flame Retardant and Insulation Resistance

Insulation PVC Tape is a pvc insulation tape with excellent electrical insulation, tensile strength, flame retardant and insulation resistance. It is suitable for electrical insulation in electrical and electronic equipment, with a tensile strength of ≥19.6N/19mm, flame retardant rating of Class B Self-extinguishing and insulation resistance of ≥20MΩ. With a length of 25m, it is an ideal tool for electrical insulation and protection.



Features:

  • Product Name: Insulation PVC Tape
  • Elongation: ≥100%
  • Temperature Range: -10℃~105℃
  • Color: Black/White/Orange/Yellow
  • Thickness: 0.1mm
  • Adhesive: Acrylates Copolymer
  • Keywords: black pvc insulation tape, pvc insulation tape, black pvc insulation tape


Technical Parameters:

Property Value
Name Insulation PVC Tape
Adhesive Acrylates Copolymer
Application Electrical Insulation
Width 9/19/25/32/38/50mm
Length 25m
Thickness 0.1mm
Flame Retardant Class B Self-extinguishing
Elongation ≥100%
Color Black/White/Orange/Yellow
Insulation Resistance ≥20MΩ


Applications:

Kablee's Insulation PVC Tape (P06) is a flame retardant wire harness tape made of high-grade PVC material, which features a high elongation of ≥100% and tensile strength of ≥19.6N/19mm. Its certification includes RoHS, REACH, ELV and IATF16949:2016, and it is classified as Class B Self-extinguishing. The tape is available in a variety of widths of 9/19/25/32/38/50mm, and can be ordered in a minimum quantity of 1 carton. Kablee also offers competitive pricing of 0.01-0.02 per carton, and fast delivery of within 5-7 days. Payment terms include T/T, PayPal, and they are able to supply up to 500 cartons per day. This Insulation PVC Tape is ideal for applications that require flame retardant and superior insulation.



Customization:

We offer the best Insulation PVC Tape with the brand name Kablee. The model number is P06. The place of origin is Guangzhou China and it is certified by RoHS/REACH/ELV/IATF16949:2016. The minimum order quantity is 1 carton. The price range is between $0.01 - $0.02. The packaging is Carton Box and the delivery time is within 5-7 days. The payment terms are T/T, Paypal and we have a supply ability of 500 cartons per day. The width of the tape is 9/19/25/32/38/50mm and the insulation resistance is ≥20MΩ. It is used for electrical insulation and comes in different colors like Black/White/Orange/Yellow. We make sure to provide our customers with the best quality PVC harness tape and PVC wire tape.



Packing and Shipping:

Insulation PVC Tape is typically packaged and shipped in boxes or on reels. The boxes and reels must be properly sealed to ensure safe transit. The product should be stored in a cool, dry place, away from any direct sunlight or moisture. Proper labeling should be included on the product to ensure that it is identifiable and easily traceable. To ensure proper safety, the product should be handled with care and not subjected to extreme temperature changes.
