Black Color Cloth Wire Harness Tape For Automotive Multipurpose

Black Color Cloth Wire Harness Tape For Automotive Multipurpose

Black Cloth Wire Harness Tape

Automotive Cloth Wire Harness Tape

Multipurpose black wire harness tape

Place of Origin:

Guangzhou China

Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
9/19/25/32/38/50mm ±0.2
Flame Retardation:
Class B Self-extinguishing
White Color
Resistance To Abrasion:
Acrylates Copolymer
Tensile Strength:
Wire Harness Tape
Temperature Range:
-40℃ (4h)~150℃ (3000h) 175℃ (240h)
Payment & Shipping Terms
Minimum Order Quantity
1 carton
Packaging Details
Carton Box
Delivery Time
within 5-7days
Payment Terms
T/T, Paypal
Supply Ability
5000 cartons per day
Product Description

Cloth Wire Harness Tape -40℃ to 150℃ & 175℃ Temperature Range for Applications

Product Description:

Cloth Wire Harness Tape is a reliable and effective product designed specifically for wire harness applications. It is made from woven PET and Acrylates Copolymer and is highly resistant to abrasion, with a rating of ≥750mm. It is capable of working in a wide range of temperatures, from -40℃ (4h) to 150℃ (3000h) and even up to 175℃ (240h). This product is available in a range of widths, including 9/19/25/32/38/50mm, with a ±0.2 accuracy. It is a perfect choice for any wire harness application, offering reliable performance and long-lasting durability.



  • Product Name: Cloth Wire Harness Tape
  • Color: Black Color
  • Material: Woven PET + Acrylates Copolymer
  • Flame retardation: Class B Self-extinguishing
  • Adhesion to Steel: 2.5N/CM
  • Abrasion resistance (Scrape): Class D 1000~4999

Technical Parameters:

Parameter Value
Color White Color
Width 9/19/25/32/38/50mm ±0.2
Flame retardation Class B Self-extinguishing
Tensile Strength ≥20N/cm
Abrasion resistance (Scrape) Class D 1000~4999
Temperature Range -40℃ (4h)~150℃ (3000h) 175℃ (240h)
Material Woven PET + Acrylates Copolymer
Total Thickness 0.25mm±0.02
Resistance to Abrasion ≥750mm
Elongation ≥10%


Kablee’s cloth wire harness tape is a high-end solution for various applications. Thanks to its RoHS/REACH/ELV/IATF16949:2016 certification, you can rest assured that it is a quality product. It is sold in cartons with a minimum order quantity of 1, and prices range from 0.01-0.03. It is delivered within 5-7 days, and payment terms are T/T or Paypal. The supply ability is 5000 cartons per day, and it is available in widths of 9/19/25/32/38/50mm ±0.2. It has a temperature range of -40℃ (4h)~150℃ (3000h) 175℃ (240h), and a total thickness of 0.25mm±0.02. It also has an abrasion resistance of class D 1000~4999, and is made from woven PET and Acrylates Copolymer.

The cloth wire harness tape from Kablee is perfect for a wide range of uses, from auto manufacturing to electronics production. It can be used to bundle and protect wires and cables, and it is easy to apply thanks to its low tack adhesive. It is also highly durable, with a temperature range that allows it to withstand extreme temperatures. It also has excellent abrasion resistance, making it ideal for environments where friction could cause damage. In addition, it is resistant to water, solvents, and chemicals.

Kablee's cloth wire harness tape is the perfect choice for any application where wires and cables need to be secured and protected. Its superior quality and excellent performance make it an ideal choice for a wide range of industries. It is perfect for auto manufacturing, electronics production, and other applications that require a reliable and long-lasting solution.



Cloth Wire Harness Tape

Brand Name: Kablee

Model Number: T04

Place of Origin: Guangzhou China

Certification: RoHS/REACH/ELV/IATF16949:2016

Minimum Order Quantity: 1 carton

Price: 0.01-0.03

Packaging Details: Carton Box

Delivery Time: within 5-7days

Payment Terms: T/T, Paypal

Supply Ability: 5000 cartons per day

Adhesive: Acrylates Copolymer

Flame retardation: Class B Self-extinguishing

Color: Black Color

Material: Woven PET + Acrylates Copolymer

Elongation: ≥10%


Support and Services:

Cloth Wire Harness Tape Technical Support and Service

We provide technical support and services for our Cloth Wire Harness Tape products. Our team is available to answer questions and provide assistance throughout the entire product life cycle.

Our technical support and service includes:

  • Product consultation and selection
  • Installation and maintenance guidance
  • Troubleshooting and repair advice
  • Product updates and upgrades
  • Warranty coverage

If you have any questions or need assistance with our Cloth Wire Harness Tape products, please contact us for more information.


Packing and Shipping:

Packaging and Shipping for Cloth Wire Harness Tape

Cloth wire harness tape should be packaged in cardboard boxes with sufficient padding to prevent movement within the box and protect the tape from external forces. Each box should be clearly labeled with the type and quantity of tape being shipped. All shipments should be tracked and insured to prevent any losses during transit.

The boxes should be sealed tightly with packing tape, and a packing slip should be included in each box. The packing slip should include the product name, quantity, and destination of the shipment. It should also include instructions on how to unpack and handle the tape.

Shipments should be sent via a reliable and secure shipping service such as FedEx or UPS. All shipments should include a tracking number so that the status of the shipment can be monitored. The tracking number should be provided to the customer upon shipment.
